All terrain crane Demag AC 40-1

Main Data:

Model / Type of crane AC 40-1 / AT

Max. capacity (75%) / max. loadmoment (tm) 40 t at 3 m / 127 tm

Year / First taken into operation 2013 / 20.11.2013

Working hours chasis (h) / date - h / 01.10.2020

Working hours superstructure (h) / date 9140 h / 01.10.2020

Mileage (km) / date 115721 km / 01.10.2020

Data Chassis:

Truck chassis type / Width K 3208 / 2,55 m

Carrier cabin no

Engine (make/type) / hp / kW DB OM 906 LA / 279 / 205

Gearbox manufacturer / Type Allison / AG / MD 3060 P

Crane driveable from above

Drive and steering 6 x 6 x 6 / 1/2/3.

Type of axle suspension hydropneumatic

Size of wheels 14.00 R 25

Sparewheel 0

Controlled from support left, right, above

Support basis L/B 6,35 x 6,20 m

TÜV / SP-acceptance validity 12.20 / 06.20

Data Superstructure:

Telescopic boom / boom sections 7,8 - 31,2 m / 5

Swing-away jib / Adapter 7,1 m - 13 m / 0/30°

No. of winches 1

Winch 1 cable pull / cable Ø 43 kN / 16 mm

Hookblocks / Crane hook (t) 32 t (DH)

Counterweight (t) 5,45 t

Working area limitation existing / available

Safe load indicator Inter Control Digsy 04 / 75 %

UVV-acceptance validity 12.20

Subject to change.

Subject to prior sale.

Complete data sheet on request.
